VE/804 Series Electromagnetic Thermal Energy Meter
Inquiry
Product introduction
The VE804 Series operates based on Faraday's Law of Electromagnetic Induction. As the conductive fluid flows through a magnetic field, it generates an induced voltage proportional to the flow velocity. This signal is converted into volumetric flow data. With dual integrated Pt1000 temperature sensors, the system simultaneously measures the supply and return fluid temperatures, enabling accurate thermal (or cooling) energy calculation in accordance with international standards.
Physical Properties
★ High Measurement Accuracy: Class 1 and Class 2
★ Nominal Diameter Range:
Inline Type: DN10 to DN300
Insertion Type: DN100 to DN2000 (ideal for retrofit or large pipeline applications)
★ Dual Pt1000 Temperature Sensors:
Factory-integrated to ensure synchronized thermal measurements
Simplifies system installation and wiring, reducing overall costs
★ Multi-Mode Functionality:
Supports heating, cooling, and combined heating/cooling applications
Automatic mode switching based on flow direction and temperature differential
★ Comprehensive LCD Display:
Real-time display of key parameters including:
▸ Thermal/Cooling Energy
▸ Instantaneous Flow
▸ Totalized Flow
▸ Supply & Return Temperatures
▸ Temperature Differential
▸ Power Output
★ Secure Parameter Management:
Password-protected digital configuration prevents unauthorized access or setting changes
★ Hot-Swap Installation (Insertion Type):
Sensor removal and replacement without shutting down the system
Ideal for continuous operation scenarios and low-maintenance environments
Ingredient Content
★ Urban & Industrial District Heating and Cooling Networks
★ HVAC Systems in commercial buildings, airports, hospitals, and data centers
★ Steam and Heat Energy Monitoring in power plants (condensate return systems)
★ Petrochemical and Chemical Plants — monitoring heat transfer in process fluids
★ Pharmaceutical and Food Industries — thermal control in heating and pasteurization processes
Product parameters
✬Smart Building Energy Management:
Installed at the inlet/outlet of HVAC systems to monitor energy usage for intelligent building automation.
✬Energy Sub-Metering for Commercial Complexes:
Provides individual tenant billing and energy consumption insights for malls, office towers, and residential high-rises.
✬District Heating Plants:
Measures thermal energy delivered to substations or end-users to ensure accurate billing and system optimization.
✬Central Chilled Water Plants (Cooling Applications):
Used to track cooling energy consumption across multiple delivery points in large campuses or industrial parks.
✬Process Heat Monitoring in Industrial Systems:
Suitable for closed-loop heat exchange systems where precise energy balance is essential.
