The MA80T Series Vortex Flowmeter is a Kármán vortex street flow meter for the measurement of steam, gases and liquids.
As the medium flows past a bluff body (typically a triangular shedder bar), alternating vortices are formed downstream. The vortex shedding frequency is proportional to the flow velocity and is detected by a piezoelectric sensor. From this frequency, the flowmeter calculates the volumetric flow rate.
With no moving parts and a robust flow body, MA80T provides stable, real-time flow measurement over a wide operating range, making it suitable for utility and process duties in demanding industrial environments.
| Item | Description |
| Measuring principle | Kärmán vortex street; vortex shedding frequency proportional to flow velocity |
| Measured media | Saturated/superheated steam, gases and clean/low-viscosity liquids (single-phase) |
| Body & flange material | SS304, SS316L; customization upon request |
| Sensor wetted material | SS304, SS316L, Hastelloy C, Hastelloy B, Titanium (model-dependent) |
| Sensor type | Piezoelectric |
| Typical accuracy (liquids) | Up to ±1.0 % of rate (under calibrated conditions) |
| Typical accuracy (gases & steam) | ±1.0 %, ±1.5 % of rate (under calibrated conditions) |
| Turndown ratio | Typically up to 1:10–1:20 (depending on medium and installation conditions) |
| Straight pipe requirement | Typically 15 × DN upstream / 5 × DN downstream (to be confirmed per installation) |
| Temperature capability | Standard up to 250 °C; high-temperature versions up to 350 °C |
| Pressure rating | Up to 4.0 MPa (model-dependent; see datasheet) |
| Process connection type | Flanged and wafer versions |
| Process connection standard | GB, DIN, ANSI (others on request) |
| Installation orientation | Horizontal and vertical pipe runs (subject to correct sizing and installation) |
| Main applications | Utility steam, gas and liquid flow measurement in process and energy systems |
| Category | Specification / Option | Notes |
| Outputs | 4-20 mA, pulse | Standard outputs for DCs/PLC integration |
| Digital communication | HART,Modbus RTU | Remote configuration and diagnostics (optional) |
| Diagnostics | Signal quality monitoring, sensor fault indication, basic self-checks | Accessible via local display or digital communication |
| Design | No moving parts; bluff-body vortex shedder with welded construction | Low maintenance, suitable for continuous operation |
| Pressure loss | Low to moderate, depending on bore size and Reynolds number | Typically lower than or comparable to office-based solutions |
| Installation | Flanged or wafer mounting; reducer-type versions available | Compatible with common industrial piping standards |
| Industry | Medium / Service | Typical Use |
| Power & Energy | Saturated / superheated steam | Boiler and turbine steam flow monitoring, heat recovery systems |
| Power & Energy | Condensate and utility water | Condensate return and utility water tracking (within vortex applicability limits) |
| Oil & Gas | Fuel gas and natural gas | Burner and furnace gas metering, gas distribution to process units |
| Oil & Gas | Steam | Steam injection and utility steam measurement for process heating |
| Chemical & Petrochemical | Utility gases (air, nitrogen, inert gases) | Compressed air and inert gas monitoring for utilities and processes |
| Chemical & Petrochemical | Clean process liquids | Dosing and transfer of clean, low-viscosity liquids |
| HVAC & District Energy | Hot/chilled water and steam | Flow monitoring in district heating/cooling and plant HVAC loops |
| Food & Beverage | Clean steam, CO₂ | Sterilization steam, carbonation gas and utility monitoring (where suitable) |
| Pharmaceutical | Clean steam in SIP systems | Steam supply for sterilization and sanitization |
| Textile & Dyeing | Process steam and utility water | Steam supply and water flow monitoring in dyeing and finishing lines |
| Pulp & Paper | Steam and condensate | Steam delivery to drying sections and condensate recovery monitoring |
As China MA80T Series Vortex Flowmeter Manufacturers and MA80T Series Vortex Flowmeter Factory, we are renowned for manufacturing professional and high-precision industrial instruments. Our expertise lies in providing unparalleled flow measurement resources, backed by over 12 years of experience solving complex applications.
Our precision flow metering devices are used by a diverse range of users, ranging from major oil and gas companies to photovoltaic providers, pharmaceutical manufacturers, and municipal services. We continuously contribute to the development of flow measurement in the domestic energy and chemical industries due to our expertise in measuring variable component gases and peculiar mediums.
